OVERVIEW

SPECS

FEATURES

SYSTEMS

PARTS LIST

BUGGY 4030

TRUGGY 4038

Input Voltage: 4S - 2650kV / 2050kV / 1900kV

                       5S - 1700kV / 1400kV

                       6S - 1400kv

Weight: 311g / 11oz

Shaft Dimensions: 5mm (.125") x 19mm

Motor Diameter: 40mm / 1.57" (42mm / 1.65" including fin)

Motor Length: 69mm / 2.71"

Bearing Dimensions: Front: 5 x 16 x 5mm / Rear: 5 x 11 x 5mm

Rotor Size: 18.5mm *all

Rebuildable: Yes



Input Voltage: 4S - 2250V / 2000kV

                       5S - 1700kV / 1550kV

                       6S - 1350kv

Weight: 368g / 13oz

Shaft Dimensions: 5mm (.125") x 19mm

Motor Diameter: 40mm / 1.57" (42mm / 1.65" including fin)

Motor Length: 77mm / 3.03"

Bearing Dimensions: Front: 5 x 16 x 5mm / Rear: 5 x 11 x 5mm

Rotor Size: 18.5mm *all

Rebuildable: Yes



 CNC Machined 6061 T6 Billet Aluminum Ribbed Heatsink Can

 Matte Anodized for Maximum Corrosion Resistance

 Sensored and Sensorless Operation

 High Current Solder Tabs

 Rebuildable Design

 Solderless Sensor PCB Replacement

 4-Pole Neodymium Sintered Magnet

 Dual-Plug Sensor Wire Harness

 ABEC5 Precision High Speed Oversized Bearings

 Precision Engineered for Maximum Energy Conversion

 Designed to be paired with the RX8 GEN2 ESC

 ROAR Approved



MOTOR ONLY



4030 BUGGY

TT2355 - 2650kV

TT2356 - 2050kV

TT2357 - 1900kV

TT2358 - 1700kV

TT2359 - 1400kV



4038 TRUGGY

TT2365 - 2250kV

TT2366 - 2000kV

TT2367 - 1700kV

TT2368 - 1550kV

TT2369 - 1350kV

RX8 GEN2 COMBO



BUGGY

TT2315 - RX8 GEN2 + T8 GEN2 2650kV

TT2316 - RX8 GEN2 + T8 GEN2 2050kV

TT2317 - RX8 GEN2 + T8 GEN2 1900kV

TT2318 - RX8 GEN2 + T8 GEN2 1700kV

TT2319 - RX8 GEN2 + T8 GEN2 1400kV



TRUGGY

TT2325 - RX8 GEN2 + T8 GEN2 2250kV

TT2326 - RX8 GEN2 + T8 GEN2 2000kV

TT2327 - RX8 GEN2 + T8 GEN2 1700kV

TT2328 - RX8 GEN2 + T8 GEN2 1550kV

TT2329 - RX8 GEN2 + T8 GEN2 1350kV



Rotors



TT2371 - T8/GEN2 4030 Buggy Rotor

TT2372 - T8/GEN2 4038 Truggy Rotor



Bearings



TT2382 - T8/GEN2 Bearing Set - Front: 5 x 16 x 5mm / Rear: 5 x 11 x 5mm



Motor Parts



TT2380 - T8/GEN2 Rebuild Kit: End Caps / Bearings / Solder Tabs / Isolator / Hardware

TT2381 - T8/GEN2 End Caps / Hardware

TT2383 - T8/GEN2 Sensor PCB

TT2384 - T8/GEN2 Solder Tabs / Isolator
